On pure AC power when no free solar energy is used, official AHRI SEER is >21. SEER is "Seasonal EER" and is a way of describing an "average EER" and considers that the system operates under part-load conditions a majority of the time. EER is equal to full-load cooling output in BTUs divided by energy input in watts. Officially, using solar does not change the SEER or the EER. However, if you consider energy input only on the basis of paid energy and don't consider the free solar energy as part of the input, using free energy from 4x 320w solar panels operating at full capacity would result in an EER of approximately 35. Because a system operates at part-load conditions a majority of the time, SEER ratings are typically much higher than EER ratings. If you tested and calculated a SEER value based only on the paid-energy, the numbers would be extremely high. Currently, there is no official test standard for testing SEER or EER based on whether or not the energy is paid for.
√Home
Keep the inside cool all day for next to nothing in energy costs. Preventing daytime heat build-up also cuts evening cooling costs.
√Office
Keep the work area comfortable during business hours for pennies per day. Cool or heat up to 50m².
√International
Compatible with 50Hz and 60Hz power, use it anywhere in the world.
√Installation
Plug-and-play solar connection
√No batteries required
√No grid power required in daytime
The air conditioner can run directly by solar panels during the day without grid-connected.
√Solar Power LED Display
The LED display shows the solar input power ratio
Advanced Air Design
• Waterfall heating, the air is directed down during the heating mode
• An added extra inner louvre operates when heating to improve airflow
• Automatically selects the airflow direction, horizontal for cooling and vertical for heating
• 10m overlong airflow
Cold Air Prevention
To prevent cold air blowing into the room when the unit is first turned on or after the defrost cycle; the indoor fan will remain off until the indoor coil reaches the desired room temperature setting.
Intelligent Defrosting
• Traditional defrosting works by running the defrost cycle based on a pre-set timer sequence.
• SuperEn new I-Defrost are only performed when needed, which reduces energy waste by eliminating unnecessary defrosting.
• Maximize warm comfort with shorter defrost times
Turbo Mode
This feature is designed to run the indoor fan at super high speed to cool or heat the room quickly so that the ambient temperature approaches the pre-set temperature as soon as possible. This allows the unit to unload quicker providing better comfort levels and energy usage
Anti-Corrosion Outdoor Unit
All SuperEn condensing coils have fin stock coated in blue hydrophilic coating giving greater corrosion resistance. All SuperEn condensing units are made from galvanized sheet steel that is then painted for added protection. Stainless steel screws are used throughout.
Better Air Quality and Noise levels
This range of Solar Hybrid Air Conditioners offers several features that improve air quality. All units come standard with filters to remove dust particles. Additional to this, each unit is fitted with – as standard - a photocatalytic filter to remove bacteria, viruses, and unpleasant odours.
The Solar Hybrid air conditioner comes with seven fan speeds so that you can choose your desired level of airflow from super low to the turbo. The auto fan feature enables the onboard logic to select the best fan speed based on the indoor temperature and the thermostat set point. The SuperEn Solar Hybrid air conditioner benefits from smart fluid dynamic design; this has dramatically improved airflow through the air conditioner thus reducing indoor noise levels.
Mould and Odour Prevention
When used as an air conditioner and once the unit is switched off the indoor coil is wet and provides a great environment for mould and bacteria to grow. By pressing the X-Fan button on the remote control the indoor fan will continue to run on for 10 minutes after the unit has been switched. This assists in drying out the indoor coil and helps to prevent the growth of mold and bacteria as well as reducing bad odors in the unit.
I Feel
Our 18000BTU ACDC Solar Inverter Ac and Solar Operated Air Conditioner Solar Powered Air Conditioning System Solar Hybrid air conditions come standard with the I-Feel remote control. This clever feature enables the unit to take the temperature reading from where we sense the indoor temperature rather than where the indoor unit senses the temperature. By pressing the "I Feel" button on the remote the room temperature is now recorded from a sensor in the remote control rather than from the unit itself. This gives intelligent temperature control where it is needed and provides a more precise and comfortable environment.
Wide Temperature Operation
Our Solar air conditioners and heat pumps are designed to operate efficiently from -15 to +52°C
| Solar Air conditioner Specification | |
| Models | Hybrid-ACDC18-US/EU |
| Nominal Capacity | 18,000 BTUh |
| Electrical Features | 100~380V DC 145~260V AC |
| Rated Power | Cooling 1.45 KW Heating 1.45 KW |
| Electric Power Input Rate | min. 0 W (with 1.8~2KW PV) |
| Energy Saving (8 hours use)* | up to 97% |
| Energy Saving (24 hours use)* | ＞50% |
| EER (Without solar) | 12.4 BTUh/W |
| COP (Without solar) | 3.59 W/W |
| Airflow Volume | 1100 m³/h |
| Refrigerant Charge | 1600 g |
| Piping Connection | Ф1/4"(6.35mm) Ф5/8"(15.88mm) |
| Dimensions | 970x315x242 mm 955x390x700 mm |
| Weight | 14 Kg 50.5 Kg |
| Loading Quantity | 140 40'HQ |
Company information
Shinson has 14+ years experiences with solar industry owned over 3G+ tier-1 Class solar panel manufacturing plants based in South East Asia.
Our product range covers Mono PERC, Bifacial, N-HJT and Flexibl, BIPV, Shingled panels, inverter, battery, soar lighting, solar air conditioner and so on.
Below are the summarized highlights by comparing with other companies:
LONG HISTROTY BRAND BORNED IN GERMANY(DE)
EXTENTED WARRANTY UP TO 20 YEARS
GLOBAL OFFICES AND WAREHOUSES
COMPETITIVE PRICES WITH FAST DELIVERY
We have the CE TUV,UL certificate, warranty 30+ years.
Product advantages
Shinson's hybrid solar air conditioner kits offer highly practical and plug-and-play solutions for residences, small commercial establishments, and remote locations. These kits contribute to energy savings and provide alternative energy solutions, particularly in areas where a traditional grid is not available.
Shinson air conditioner PV systems allow installers to connect them to the AC main service panelof any house. Owners are given the option to either consume the power generated from their PV system day time or from the grid night time. These systems are provided with 180° sine wave DC inverter controller technology for inverter air conditioner, "SVPWM" which makes the compressorranat low frequency below 0.1Hz, improve the utilization of the DC compressor by 13% compared with120 DC inverter controller technology by 32% compared with Non-inverter air conditioner.
Components of air conditioner:
1. Indoor unit: 1pcs
2. Outdoor unit: 1pcs
3. Wireless remote control: 1pcs
4. Copper pipe: 3 meters
5. Solar Cables: 12 meters
6. MC 4 cable connector: 2pcs
7. DC breaker: 2pcs
8. Water drain hose: 1pcs
9. AAA Battery: 2 pcs
10. installation rape belt: 1pcs
11. User installation manual: 1pcs
12. Solar panel (Optional)
13. Battery (Optional)
