Features
(1)Shinson 12000btu solar hybrid air conditioner for home use can operate independently of AC Grid and turn itself off when there is insufficient solar power and back on when there is enough power to operate.
(2)No grid connection for installation, no utility company authority required.
(3)Plug and play installation - solar panels connect directly to solar terminals.
(4)Uses eco-friendly R32 refrigerant.
(5)Brushless DC motors in both indoor and outdoor units can keep quiet operation.
Product Details
Shinson 12000btu solar hybrid air conditioner for home use requires no batteries, and only a few PV panels to deliver huge savings. During the day, when air conditioning is needed the most, you can operate this unit partly or up to 100% by it's independent solar panels to achieve maximum eficiency. At night, you can continue to save due to it's high efficiency.
The WlFl functionality allows full control, daily and weekly timers, complete visibility with AC and DC consumption and the history of all power consumption.
Technical Specifications
| Shinson Model | SAH-12K-R | ||
| Max electrc curent/Peak curent | A | 12/15 | |
| Power Supply |
Rated Voltage | V~ | 208-240 |
| Rated Frequency | Hz | 50/60 | |
| Solar DC | V | 70-350 | |
| MinMax Voltage | V~ | 150/265 | |
| Solar Dc Current | Max Currert | A | 12 |
| Rated Currert | Cooling Rate Current(T1) | A | 3.85 |
| Cooling Rate Current (T3) | A | 4.48 | |
| Heating Rate Currert | A | 4.02 | |
| Rated Power | Cooling Rate Power (T1) | W | 860 |
| Cooling Rate Power (T3) | W | 963 | |
| Heating Rate Power | W | 905 | |
| Min. Power Input | W | 180 | |
| Max. Power Input | W | 1500 | |
| Cooling Capacity(T1) | W | 3500 | |
| Btu/h | 12000 | ||
| Cooling Capacity(T3) | W | 2800 | |
| Btu/h | 9600 | ||
| Min Cooling Capacity | W | 1300 | |
| Btu/h | 4500 | ||
| Max Cooling Capacitly | W | 3950 | |
| Btu/h | 13500 | ||
| Heating Capacity | W | 3500 | |
| Btu/h | 12050 | ||
| Min Heating Capacity | W | 1130 | |
| Btu/h | 3850 | ||
| Max Heating Capacity | W | 4300 | |
| Btu/h | 14600 | ||
| EER | W/W | 4.02 | |
| Btu/W | 13.74 | ||
| SEER | Btu/W | 23.00 | |
| COP | W/W | 3.87 | |
| Btu/W | 13.34 | ||
| HSPF | Btu/W | 9.70 | |
| Application Area | m2 | 14~24 | |
Shinson has been in the solar industry for over 14 years, and committed to designing and manufacturing high-quality products.
Our solar air conditioners combine the advantages of high efficiency, low noise, energy saving, safety and environmental protection.
We sell our products to more than 100 countries such as France, DE, UK, Lithuania Serbia, Algeria, Holland, Poland, /Burkina Faso, Nigeria, USA, United Arab Emirates and so on with the most professional service, and CE, TUV, UL certificate.
We have focus on solar air conditioner for 10 years ,and we alsohave a wide range of solar products such as solar panels, inverters, batteries, solar lights and so on.
We are reliable supplier with good quality and all your requirements are most important to us.
We will provide you with competitive prices, best service and continuous benefits.
